The device is DC high frequency portable dental x-ray unit, small,light and nearly no radiation.
Tube voltage:60KV
Tube current:1.5mA
Exposure time:0.1-2s
Frequency:30KHz
Tube focus:0.3mm×0.3mm
The distance from skin to cone:130mm
Battery:DC14.8V 6400mAh
Rated power:60VA
Charger input voltage:AC100V-240V±10%
Output voltage:DC16.8V
Ambient temperature:5-40℃
Relative humidity:<75%RH
Net Weight:2.5kg
Gross Weight:4.8kg
Package size:33×31×23cm
1.The device is DC high frequency portable dental x-ray unit, small,light and nearly no radiation.
2.There are manual buttons installed on the surface of shell,operate easily. All of the components are installed in the central PC board. Insulation vacuum and sealed stereotype protection made its brilliant features.
3.The unit mainly suitable for oral pre-treatment diagnosis of internal organization structure and root depth and so on, is indispensable in daily life clinic,especially for dental implant surgery.
4.The battery is durability,it can take about five hundred images after full charged, and it can be charged and discharged for one thousand times in its life.
5.It can be connected with intra-oral digital x-ray imaging system.
Voltage | AC 100V ~ 240V ±10%, |
Tube Voltage | 60kVP(Fixed) |
Tube Currect | 1.5mA |
Focus Size | 0.8mm |
Exposure Time | 0.01-2 Sec |
N.Weight | 2.5Kg |
G.Weight | 5Kg |
Dimension | 31x31x23CM |
Warranty | 1 Year |
Recende Medical manufacture and export Dental Equipment & Dental Materials over 12 years, approval ISO13485:2016 and CE certificate. You will get Good Service, Good Quality & Better Price from us. We will do our best for your health!
